Amana® Air Conditioner Condenser, Model: ASXV9, 4 ton Nominal Capacity, 48000 Btu/hr, 208/230 V, 30.1 A, 1/2 hp, 60 Hz, 1 ph Phase, Variable Speed Swing and Scroll Compressor, 18.6 to 19.5 SEER, R-410A Refrigerant, 3/8 in Liquid Line, 1-1/8 in Suction Line, 75 dBA Sound Level, Inverter Drive, C Connection, 35 A Fuse Rating, Variable Speed Motor, 65 to 115 deg F, Steel, Finish: Baked-On Powder-Coated/Galvanized, 41-3/4 in H x 35-1/2 in W x 35-1/2 in D, Additional Information: TXV Expansion Device

• ComfortBridge™ technology 'bridges' indoor comfort with smart technology and is factory installed into select, premium Amana® brand gas furnaces and air handlers
• ComfortBridge™ technology helps your Amana® brand air conditioner heating and cooling systems cost effectively operate at peak performance
• In the past, communicating technology was limited to a few expensive, proprietary thermostats
• Now, ComfortBridge™ technology is installed securely in Amana® brand furnace and air handler equipment, providing you consistent, energy efficient home comfort
• You can be assured that your Amana® brand air conditioner will provide you with quiet operation
• To minimize operating sounds, we've acoustically engineered our systems with enhancements such as a specially designed sound control top
• Energy efficiency equates to cost savings. Your Amana® brand AVXC9 air conditioner offers up to 22.5 SEER2 energy efficiency performance
• SEER2 stands for Seasonal Energy Efficiency Rating, a measure used by the US department of energy to rate the cooling efficiency of air conditioners and heat pumps
• The higher the SEER2, the greater the efficiency and the lower the operating cost
• Compared to lower SEER2 units found in many homes, an Amana® brand AVXC9 air conditioner provides significant savings on your electric bill
• Variable speed swing and scroll compressors
• High density compressor sound blanket
• Integrated communicating ComfortBridge™ technology
• Commissioning and diagnostics via indoor board Bluetooth® with the CoolCloud™ phone and tablet application
• Variable speed DC outdoor fan motor
