Amana® AHVE Series AHVE60DP1400 Corporate Air Handler With Internal EEV ComfortBridge™ and Inverter, 60000 Btu/hr BTU
- Item ID: AHVE60DP1400
- Min. Order Qty: 1
- Item ID: AHVE60DP1400
- Brand: Amana®
-
-
Amana® Corporate Air Handler, AHVE Series, 5 ton Nominal Capacity, 60000 Btu/hr Cooling Capacity, 60000 Btu/hr, 208/230 V, 6.5 A, 3/4 hp, 60 Hz, 1 ph Phase, Horizontal, Vertical, FPT Connection, R-410A Refrigerant, 15 A Fuse Rating, 3/4 in Connection, 3/8 in Liquid Line, 7/8 in Suction Line, ECM Motor, Finish: Painted, 53-7/16 in H x 24-1/2 in W x 21 in D, Additional Information: Electronic Expansion Valve, Multi-Position, Variable Speed
- Electronic expansion valve (EEV) for cooling and heat pump applications
- 7 mm evaporator coil tube size
- Variable speed ECM blower motor
- Compatible with the Amana® brand smart thermostat
- Provides constant CFM over a wide range of static pressure conditions independent of duct system
- CFM indicator
- Thermostat provides adjustable low CFM for efficient fan only operation
- All aluminum evaporator coil
- Fault recall of six most recent faults
- Improved humidity and comfort control
- Coil-mounting track for quick repositioning
- Rigid SmartFrame™ cabinet
- Cabinet air leakage less than 2% at 1 in H2O when tested in accordance with ASHRAE standard 193
- Cabinet air leakage less than 1.4% at 0.5 in H2O when tested in accordance with ASHRAE standard 193
- 21 in D for easier attic access
- DecaBDE-free thermoplastic drain pan
| Additional Information | : | Electronic Expansion Valve, Multi-Position, Variable Speed |
| Amperage Rating | : | 6.5 A |
| BTU Rating | : | 60000 Btu/hr |
| Cabinet Configuration | : | D |
| Configuration | : | Horizontal, Vertical |
| Connection Size | : | 3/4 in |
| Connection Type | : | FPT |
| Cooling Capacity | : | 60000 Btu/hr |
| Dimensions | : | 53-7/16 in H x 24-1/2 in W x 21 in D |
| Efficiency | : | SEER2 |
| Expansion Type | : | EEV |
| Finish | : | Painted |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 15 A |
| HP Rating | : | 3/4 hp |
| Heating Capacity | : | NO HEAT |
| Item Name | : | AHVE |
| Liquid Line Size | : | 3/8 in |
| Motor Type | : | ECM |
| Nominal Capacity | : | 5 ton |
| Number of Phases | : | 1 PHASE |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Series | : | AHVE Series |
| Speed | : | VARIABLE SPEED |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 5 TON |
| Type | : | RESIDENTIAL |
| Voltage Rating | : | 208/230 V |
| Wireless Communication | : | YES |
No documents
Amana® AHVE60DP1400
