DAIKIN FDMQ FDMQ24WVJU9 Ducted Concealed Indoor Multi-Zone Heat Pump, 208/230 V, 13.1 A, 24000 Btu/hr BTU, 0.31 hp
- Item ID: FDMQ24WVJU9
- Min. Order Qty: 1
- Item ID: FDMQ24WVJU9
- Brand: DAIKIN
-
-
The FDMQ ducted concealed indoor unit provides external static pressure capabilities of up to 0.6, allowing for longer duct runs and easy implementation of high MERV filters. This ducted unit on a multi-zone system delivers heating and cooling comfort for the entire home, without distracting from decor. With up to 17.9 SEER2 level, FDMQ ducted concealed indoor unit is ENERGY STAR certified.
DAIKIN Ducted Concealed Indoor Multi-Zone Heat Pump, Model: FDMQ, 208/230 V, 13.1 A, 2180 W, 2345 W, 0.31 hp HP Rating, 60 Hz, 1 ph, 3 Number of Fan Speeds, 24000 Btu/hr, 731 cfm CFM Rating, 12.7 EER, 20.2 SEER, HSPF: 10.6, Swing Compressor, R-410A, 20 A Fuse, 2 ton, 40 dBA, Ceiling Mount, 39-3/8 in Overall Width, 9-5/8 in Overall Height, Additional Information: 31-1/2 in D Dimension
- Capable of providing external static pressures
- Integral lift mechanism with 29-9/16 in of lift
- Drain pan inspection port makes it easy to observe drain pan conditions
- No optional adapter needed for DIII connection
- Link your unit into the wider building management system
- Compatible with the DAIKIN Zoning Kit (DZKS)
| Additional Information | : | 31-1/2 in D Dimension |
| Amperage Rating | : | 13.1 A |
| BTU Rating | : | 24000 Btu/hr |
| CFM Rating | : | 731 cfm |
| Compressor Type | : | Swing |
| EER Rating | : | 12.7 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| HP Rating | : | 0.31 hp |
| HSPF Rating | : | 10.6 |
| Model | : | FDMQ |
| Mounting Type | : | Ceiling |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 9-5/8 in |
| Overall Width | : | 39-3/8 in |
| Phase | : | 1 ph |
| Power Rating | : | 2180 W, 2345 W |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 20.2 |
| Sound Level | : | 40 dBA |
| Tonnage | : | 2 ton |
| Voltage Rating | : | 208/230 V |
