Mars® 10592 PSC Direct Drive Blower Motor, 1 hp, 208 to 230 V, 60 Hz, 1 ph-Phase, 48 Frame, 1075 rpm Speed
- Item ID: 10592
- Min. Order Qty: 1
- Item ID: 10592
- Brand: Mars®
-
-
Mars® direct drive furnace blower motors are three speed standard efficiency models. All models are electrically reversible and include 2-1/4 in resilient rings for base mounting. These models have all angle sleeve bearings and have open air over enclosures.
Mars® PSC Direct Drive Blower Motor, 1 hp HP Rating, 208 to 230 V, 5.6 A, 60 Hz, 1 ph, 1075 rpm Speed Rating, 1 Speed, Open Air Over, 48 Frame, 0.5 in Dia x 4.49 in L Shaft, Sleeve Bearing, Extended Stud, Resilient Ring Mount, -10 to 40 deg C, Insulation Class: Class B
- Rheem mounting holes
- 1/2 in extended thru-bolts
- Thermal overload protected
- Fan duty, continuous and air over
- Open construction
- 36 in leads
- Reversible rotation
| Amperage Rating | : | 5.6 A |
| Bearing Type | : | Sleeve |
| Enclosure Type | : | Open Air Over |
| Frame | : | 48 |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1 hp |
| Insulation Class | : | Class B |
| Mounting Type | : | Extended Stud, Resilient Ring |
| Number of Speeds | : | 1 |
| Phase | : | 1 ph |
| Shaft Size | : | 0.5 in Dia x 4.49 in L |
| Speed Rating | : | 1075 rpm |
| Temperature Rating | : | -10 to 40 deg C |
| Voltage Rating | : | 208 to 230 V |
Mars® 10592
