Glasfloss® Z-Line® Series ZLP18201 Air Filter, Pleated Filter, 18 in W, 20 in H, 1 in D, 10 MERV
- Item ID: PL18201
- Min. Order Qty: 1
- Item ID: PL18201
- Brand: Glasfloss®
-
-
The Glasfloss Z-Line® Series pleated filters offer improved performance for virtually every application. All Glasfloss Z-Line® pleated filters feature fibers which do not absorb moisture and will not support microbial growth. The Z-Line® Series pleated filter offers excellent performance and value for a wide range of applications, HV filters are ideal in high-velocity systems where maximum square footage of media is necessary.
Glasfloss® Air Filter, Series: Z-Line® Series, Pleated Filter, Synthetic Media, 18 in Width, 20 in Height, 1 in D, MERV: 10, 4.32 sq-ft Media Area, 14 ft Pleats per Linear Feet, 300 fpm Rated Velocity, 0.2 in-WG Initial Resistance, 1 in-WG Final Resistance, 19-1/2 in H x 17-1/2 in W x 7/8 in D Actual Size, 180 deg F
- MERV 10
- Heavy-Duty Moisture Resistant Construction
- Galvanized Expanded Metal Backing
- Standard Size 4" and 6" Thick
- Incorporate Media Separators
| Actual Size | : | 19-1/2 in H x 17-1/2 in W x 7/8 in D |
| Depth | : | 1 in |
| Filter Type | : | Pleated |
| Final Resistance | : | 1 in-WG |
| Frame Material | : | Beverage Board |
| Height | : | 20 in |
| Initial Resistance | : | 0.2 in-WG |
| MERV | : | 10 |
| Media Area | : | 4.32 sq-ft |
| Media Material | : | Synthetic |
| Pleats per Linear Feet | : | 14 ft |
| Rated Velocity | : | 300 fpm |
| Series | : | Z-Line® Series |
| Temperature Rating | : | 180 deg F |
| Width | : | 18 in |
Glasfloss® ZLP18201
